產品規格：
Circuit:SPST
Rating:1A/36VDC
Rating:1A 125VAC/0.5A 250VAC
Dielectric withstanding voltage:1000VAC for 1 minute
Contact Resistance:100mΩ Max .(intial)
Insulation Resistance:100MΩ Min.
Operating Force:400±100gf
Total Travel:2.0±0.5mm
Opearating Force:10,000 Cycles Min
Soldear Specifications:256℃ for 5 Seconds
Function:ON-OFF OFF-(ON)
Openrating Temperature:-20℃~+70℃
應用領域：
Lighting Fixtures 照明燈具
Automated production 自動化生產
Instruments and meters 儀器儀表
Professional Audio 專業音響
Testing equipment 檢測設備
Electrical toys 電動玩具
